Description
| Input Type |
Single Phase
|
|---|---|
| Input Voltage |
88 ~ 264VAC
|
| Input Current |
0.55A /230VAC
|
| Output Voltage |
CH1: 5V, CH2: 12V
|
| Output Current |
CH1: 4A, CH2: 1A
|
| Rated Output Power |
32W
|
| Output Type |
Dual
|
| Output Voltage Adjustment |
CH1: 4.75 ~ 5.5V
|
| Alarm Signals |
N/A
|
| Dimming / Control Options | |
|---|---|
| Prescribed Electrical Item |
No
|
| SELV |
Yes
|
| Efficiency |
79.00%
|
| Operating Temperature Range | |
| Warranty |
3 Years
|
| Approvals |
CE,CB,RCM
|
| IP Rating / Environmental Protection |
Less than IP65
|
| Dimensions |
99*82*36mm (L*W*H)
|
| Recommended for New Designs |
Yes
|
